Print specifications for a 3D printer
FDM (Fused Deposition Modeling)
| Minimum Wall Thickness: | 1,0 mm |
| Minimum Detail: | 0,4 mm |
| Accuracy: | ± 0,3 mm |
| Maximum Size: | 279(diameter)×638 mm |
SLA/STL (Stereo lithography )
| Minimum Wall Thickness : | 0,8 mm |
| Minimum Detail: | 0,3 mm |
| Accuracy: | ± 0,2% |
| Maximum Size: | 2100×700×800 mm |
SLS (Selective Laser Sintering)
| Minimum Wall Thickness : | 1,0 mm |
| Minimum Detail: | 0,1 mm |
| Accuracy: | ± 0,2 mm |
| Maximum Size: | 1100×690×590 mm |
DLM Metall (Direct Laser Melting)
| Minimum Wall Thikness: | 0,5 mm |
| Minimum Detail: | 0,05 mm |
| Accuracy: | ± 0,05 mm |
| Maximum Size: | 250×250×310 mm |
PolyJet (Photopolymer Jetting)
| Minimum Wall Thickness: | 0,8 mm (0,4 mm in special cases) |
| Minimum Detail: | 0,05 mm |
| Accuracy: | ± 0,1 mm |
| Maximum Size: | 302×280×150 mm |
FullColor (Zprint)
| Minimum Wall Thickness: | 1,5 - 2,0 mm |
| Minimum Detail: | 0,8 mm |
| Accuracy: | --- |
| Maximum Size: | 254×381×204 mm |
Ceramic (does not apply to industrial ceramics)
| Minimum Wall Thickness: | 3-6 mm |
| Minimum Detail: | 2 mm |
| Accuracy: | ± 3% (zzgl. 1mm Glasur) |
| Maximum Size: | 340 x 240 x 200 mm |
Greenstate Metal (Greenstate)
| Minimum Wall Thickness: | 1-3 mm |
| Minimum Detail: | 0,8-1 mm |
| Accuracy: | ± 3-4 % |
| Maximum Size: | 762 x 393 x 393 mm |
Precious Metals (Lost Wax)
| Minimum Wall Thickness: | 0,5 mm |
| Minimum Detail: | 0,3 mm |
| Accuracy: | ± 0,1 |
| Maximuum Size: | 88 x 63 x 125 mm |
