Material-Details: Material details: zirconium dioxide, ZrO2 Datasheet



ZrO2. Material with very good mechanical properties at low temperatures, which can be colored for applications in jewelery. Excellent mechanical properties at high temperatures, low thermal conductivity at ambient temperature, electrical conductor at T > 1000 C, high hardness, good wear resistance, good chemical resistance, good resistance to metals.


Advantages & disadvantages

Advantages
  • Very solid
  • High Resolution
  • High temperature resistance
  • Good conductivity at >1000°C
  • Good wear resistance
Disadvantages
  • Fragile
  • Not predictable automated

Price calculation

Industrial Ceramics can be calculated only manuel

  • Manual request

Typical usage

Zirconium dioxide is used due to its good thermal resistance as refractory ceramics as technical ceramics in engineering, as well as restorative materials in medical technology.
Zirconia is also in medicine among others, hip joint implants and dental medicine as a basis for the manufacture of Crown and bridge substructures using CAD/CAM techniques, root pins and metal-free dental implants to the application.


Technology

ZrO2 is produced in the FCP procedure.FCP means almost ceramic production and is a variation of the SLA process with subsequent refining through burning.

The procedure:

Your model is broken down into layers of 0.2 mm on the computer.
They are sent to the printer. The printer put a 0.2 mm thick layer of a ceramic resin mixture. This mixture hardens now in places where your part is to be created, by a UV laser.
This process is repeated until the component is created.
Now your part is burned, it escapes the resin and compressed the component.
In the end result is a dense ceramic material which is even medically useful.


Cermaic 3D printing technology clarification, methods

Additionnal information

Shipping within
on demand


Design specifications:

Tolerance
n/a

Minimum wall thickness
0,2

Smallest Detail
0,05

Maximum dimension
coming soon


Priority service

For brass no priority service is available

Price
---




Post-production services will be updated soon. High gloss polishing und Coloring on demand.



Available colors:

White;, more coming soon



Unit Value
Flexural strength g/cm³ 6
Compressive strength MPa n/a
Fracture toughness MPan1/2 n/a
Thermal resistance C 2680°C
Impact resistance kJ/m n/a
E-Modul GPa n/a
Water absorption % 0
Chemical resistance Very resistant
Weather Resistant
